HP Labortechnik present their latest autoclave equipment: VARIOKLAV® 25 TV

HP Lab VARIOKLAV

The VARIOKLAV® 25 TV weighs a total of 75 kg and is extremely compact. It contains an integrated storage tank for feed water and a chamber heated by a double jacket. The refurbished table unit with a useful volume of 25 litres itself consists of a robust, powder-coated stainless steel housing and can be used for simple or demanding sterilisation processes.

HP LabAreas of application

The table autoclave VARIOKLAV® 25 TV is suitable for the sterilisation of liquids, nutrient media and solutions as well as waste, in open or slightly closed containers. Porous and solid materials, rubber articles, pipette tips, glassware, instruments, even filter housings or consumables can be safely sterilised.

A specially developed vacuum pump reliably removes air pockets in hollow bodies or destruction bags. Here microorganisms and infectious, septic material are safely inactivated with a fractionated pre-vacuum.

Product benefits

  • Diaphragm vacuum pump, also for water vapour and high humidity
  • Two important rights and heated pump heads are the suction power and the condensate formation
  • Exact drying temperatures thanks to steam-heated double jacket
  • Water feed from the exiting storage tank provides a minimal amount of inert gas in the early steam

Features

  • Operating pressure of the chamber +4 bar (abs) and vacuum
  • Sterilisation temperature adjustable between 105°C and 134°C
  • Double jacket as steam generator (shortens batch time, saves resources)
  • Minimal feed water consumption (several batches per tank filling)

Hygiene and safety

  • Steam-sterilisable filter candle with display for changing the sterile filter
  • Easy cleaning thanks to smooth and easily disinfectable stainless steel surfaces
  • Drip water strip (removable) under the door
  • Valve-free blocks
  • A thermal barrier ensures safe removal of liquids without delay in boiling
  • Tested according to the EU Pressure Equipment Directive
  • Refurbished device from the autoclave manufacturer

Expansion stages

Rapid cooling of liquids in infusion bottles, drying in a sterile air stream, special programs, prion programs with higher sterilisation temperatures, including with exhaust air filtration, decontamination of equipment.

Equipment

Chamber insertion system for sieve baskets and sterilisation containers, trolleys, under-frame, test systems for steam penetration, consumables, equipment for validation and recommissioning.

HP VARIOKLAV

To learn more about the range of analytical and medical device products & services HP Labortechnik have to offer, head to their listing here.
